Hobbywing Xerun XR10 Pro Legacy Brushless Regler 150A, 2s LiPo
Hobbywing XeRun XR10 Pro Legacy Brushless ESC
The XR10 Pro Legacy brings the legendary XR10 Pro look to the latest technical standard! A modern 32-bit M4 processor ensures lightning-fast response times and high data processing performance, while the integrated smart fan activates cooling only when needed, extending its lifespan. In addition, a built-in reverse polarity protection circuit safeguards against incorrectly connected batteries – for worry-free operation on race day.
Using the optional OTA Bluetooth module and the HW Link App, all parameters can be conveniently adjusted via smartphone, firmware can be updated, and real-time data (throttle, voltage, temperature, RPM, etc.) can be monitored. The data is stored directly on the OTA module – perfect for post-run analysis after practice or racing. Also new is the enhanced Softening Function, which helps drivers manage challenging track conditions!
Features:
- 32-bit M4 processor: ultra-fast signal processing and expandable functionality.
- Smart fan control: activates only when needed for longer fan life.
- Integrated reverse polarity protection
- Real-time data logging via OTA: monitoring and recording
- Softening function: smoother throttle response on slippery surfaces.
- Wide range of applications: 1/10 on-road & off-road racing, drift, F1, rally
Technical Specifications:
| Type: |
Brushless, sensored ESC |
| Continuous / Peak Current: |
150 A / 1000 A |
| Input Voltage: |
2S LiPo |
| BEC: |
Switch mode, 5.0–7.4 V, 5 A continuous / 10 A peak |
| Motor Limit: |
Touring ? 4.5T, Buggy ? 5.5T, 3650(540) 2-pole motor |
| Fan: |
Yes, intelligent start/stop function |
| Programming: |
OTA Bluetooth module (HW Link App) |
| Dimensions: |
37.7 x 37.0 x 33.2 mm (with fan) |
| Weight: |
94.2 g (with wires) |
| Applications: |
1/10 on-road & off-road racing, 1/10 drift/F1/rally |
